Unwinding Unit

-Automatic tension control system

-Edge alignment correction

-Intermittent Die-Cutting Unit

Independent servo motor direct drive

-Three-roller independent wall panel module design

-Advanced pre-registration device

-Waste Removal Unit

Rewinding Unit

-Independent motor direct drive

-Automatic tension control system

Optional

-Optional die-cutting edge trimming and slitting knives

-Optional collection table, same as in-mold die-cutting

-Optional cutting unit

-Optional snowball waste removal system

Paper Width Range: 100mm - 340mm

Die-Cutting Width: 100mm - 330mm

Unwinding/Recoiling Shaft: 76’’ (3’’)

Max Unwinding Diameter: 700mm

Max Rewinding Diameter: 700mm (Lower) / 500mm (Upper)

Max Intermittent Speed: 60m/min

Max Full Rotation Speed: 120m/min

Intermittent Die-Cutting Length Range: 80mm - 350mm

Registration Accuracy: ±0.15mm

Power Supply: 380V, 50/60Hz, 20KW

Machine Weight: 3000KG
