Key Features of This Machine:

✔ Automatic Tension Control – Ensures consistent tension during unwinding and winding for smooth operation.
✔ Automated Glue Supply System – Precisely controls adhesive application for uniform coating.
✔ Meter Shutdown Function – Automatically stops the machine at a preset length for accurate production.
✔ Automatic Roll Diameter Stop – EPC (Edge Position Control) Maintains proper alignment for error-free material handling.
✔ Adjustable Displacement Winding – Allows customizable winding configurations for different material types.
✔ Twinkle Lamp Indicator – Provides visual alerts for operational status and warnings.
✔ Automatic Width Measurement – Ensures precise material width tracking for consistent output.

Specification:

Maximum Mechanical Speed: 450 m/min
Max. unwinder Web Width: 520/620/720 mm
Sleeve width: 30-250/300/350 mm
Maximum Rewinding Diameter: .900 mm
MaximumUnwinding Diameter: 500 mm
Equipment Dimension: L3100 mm x W1800 mm x H1900 mm
Registration Accuracy:  0.2 mm
Power: 380 V, 3 phase, 9 kW
