Inclined Silk Screen Printing
The inclined silk screen printing machine handles label printing for various industries, such as wine & spirits, electronics, cosmetics, pharmaceuticals, packaging, automotive, toys, logistics, apparel, and security applications.

  • Product Introduction
  • Technical Parameters

Key Features of This Machine:

✔ Unwinder with web guiding system  Unwinds material while keeping it aligned.
✔ Semi/full rotary flexo for printing, varnishing, and lamination  Prints, applies varnish, and laminates with flexo technology.
✔ UV drying system  Cures ink quickly using UV light.
✔ High-speed inclined silk screen unit  Prints at high speeds with an inclined setup.
✔ Semi/full rotary die-cutting station  Cuts labels using rotary technology.
✔ Snowball waste rewinder – Collects and rewinds waste material.
✔ Rewinder – Rewinds processed material into rolls.

Specification:

Maximum Unwind Outer Diameter: 700 mm
Maximum Rewind Outer Diameter: 700 mm (500 mm for upper rewind)
Maximum Waste Outer Diameter:
600 mm
Maximum Web Width: 340/380/430 mm
Maximum Printing / Die Cutting Width: 330/370/420 mm
Silk Screen Size:
L380*W330/370/420 mm
Silk Screen Speed:
20~25 m/min
Maximum Die-cutting/Print Speed (Full-rotary): 120 m/min
Maximum Die-Cutting/Print Speed (Semi-rotary): 200 repeats/min
Registration Accuracy:  ± 0.15 mm
Power supply: 380V,3Phase, 41KW
