Combination Label Finishing Line

The printed label materials, available in roll-to-roll or roll-to-sheet formats,are ideal for use in industries such as electronics, cosmetics, packaging, pharmaceuticals, transportation, toys, logistics, and security.

Product Introduction
Technical Parameters

Key Features of This Machine:

✔ Flexo Semi/Full Rotary Stations – Two versatile stations for cold foil application, varnishing, or lamination, with quick key-based interchange between semi-rotary and full-rotary modes.
✔ Flatbed Hot Stamping Station – Equipped with an optional foil-saving system and a 90° rotatable foil head for enhanced adaptability.
✔ Material Handling Capabilities – Includes de-lamination, re-lamination, and turn bar functions to manage material layers and ensure correct orientation.
✔ Precision Lamination Registration – Ensures exact alignment for flawless lamination results.
✔ Semi/Full Rotary Die-Cutting – Seamless switching between semi-rotary and full-rotary cutting modes for flexible production needs.
✔ Integrated IML Conveyor System – Streamlines the collection of in-mold labeled products for improved workflow efficiency.

Specification:

Maximum Unwind Outer Diameter: 700/800 mm

Maximum Rewind Outer Diameter: 700/800 mm (500 mm for upper rewind)
Maximum Waste Outer Diameter: 600 mm

Maximum Web Width: 340/430/530 mm

Maximum Die Cutting Width: 330/420/520 mm

Maximum Speed (Semi-rotary): 60 m/min
Maximum Speed (Full-rotary): 120 m/min
Semi Rotary Die Cutting Repeat Range: 50-300 mm/80-400 mm

Registration Accuracy: ± 0.15 mm

Power supply: 380V, 3Phase, 35 KW
