FS370/420/430/450 Flexo Printer

Flexo printer (flexographic printer) is an excellent choice for printing
adhesive labels,film labels, In-mold labels, and shrink sleeves.

Product Introduction
Technical Parameters

Key Features of This Machine:

✔ Precise registration – Essential for multi-color printing.
✔ UV or EB drying systems – Fast curing for films and sleeves.
✔ High-resolution anilox rollers – Ideal for detailed graphics and smooth color transitions.
✔ Automated tension control – Crucial for managing film and shrink sleeve materials.
✔ Inline finishing options – Includes lamination and die-cutting capabilities.

Specification:

Model	NSL-FS-370	NSL-FS-430
Voltage/Hz:	380V/50Hz	380V/50Hz
Power:	40W	40W
Phase	3P+N+PE	3P+N+PE
Weight:	10T	10T
Maximum Unwind OD	1000mm	1000mm
Maximum Rewind OD	800mm	800mm
Maximum Waste OD	700mm	700mm
Maximum Web Width	380mm	440mm
Maximum Die Cutting Width	370mm	430mm
Die Cutting Repeat Range	370mm(15° magnet cylinder)	430mm(15° magnet cylinder)
Registration Accuracy	± 0.1mm	± 0.1mm
Power supply	380V (depends on customers’ requirement)	380V (depends on customers’ requirement)
Maximum blade speed	200 m/mins	200 m/mins
